Pixel pitch

0.8 mm

1.2 mm

1.5 mm

1.6 mm

2.5 mm

Detector length

102.5 mm

76.3 mm

96.8 mm

101.6 mm

160.4 mm

Min integration time

179 μs

147 μs

Max Qty of detectors supported

32 pcs

40 pcs

Crystal material for low energy scintillator

Film GOS, etc.

Crystal material for high energy scintillator

CsI(Tl)，GGAG，ceramic GOS, etc.

Filter

0.6mm copper, etc.

Gain range

0.5 pF – 31.5 pF

Gain step

0.5 pF

A/D precision

16 bits

Network interface

Gigabit Ethernet

Power supply

+12V - +24V

Application/storage temperature

-10℃ - 60℃ / -40℃ - 60℃

Application/storage humidity

<80% RH (no condensation) / <95% RH (no condensation)
